RAD.1 - Tank monitoring and remote control

Features:

  • Temperature / Flow / Pressure / Cryogenic tank
  • Industrial Gas Meter Reading
  • Flow Computer Features
  • Universal Multi-Operator Carriers
  • Event Log

Benefits:

  • Efficient and accurate monitoring of tank levels and conditions
  • Real-time measurement and control of temperature, flow, and pressure
  • Reliable data for gas consumption and billing with industrial gas meters
  • Enhanced flow management with advanced computer features
  • Flexible support for multiple operators and configurations
  • Detailed event history for troubleshooting and analysis

RAD.1 - Tank monitoring and remote control

Versions

Cod.: TL.014.410 + -
Cod.: TL.014.411 + -

Spare parts and Options

Cod.: TL.014.41A.1 + -

BATTERY SUPPLY BOARD FOR RAD.1 (ONLY FOR TL.014.410). SUITABLE FOR UP TO 2x D-CELL BATTERIES (NOT INCLUDED). ATEX II 1G EX IA GA IIB T2 X TL.014.41A.1




Cod.: TL.014.41A.2 + -

BATTERY SUPPLY BOARD FOR RAD.1 (ONLY TL.014.411). SUITABLE FOR UP TO 2x D-CELL BATTERIES (NOT INCLUDED). ATEX II 1G EX IA GA IIB T2 X

Cod.: TL.014.41A.3 + -

POWER SUPPLY BOARD FOR RAD.1 EXTERNAL SUPPLY INPUT 12Vdc OUTPUT 3.6Vdc

Cod.: AC.040.028 + -

LITHIUM METAL BATTERY 3.6V D CELL - 18Ah (SPARE ONLY FOR TL.014.41X)

RAD.1 is a control unit designed for the remote management of OIL, LUBRICANT, LPG, ADBLUE TANKS, TECHNOLOGICAL SYSTEMS, PIPELINES, LEVEL CONTROL, SKID, VAPORIZER, and FLOW CONTROL.
The device is equipped with configurable digital and analogue inputs, allowing the control and measurement of different physical quantities: level, pressure, temperature, weight, or threshold, as well as digital and/or pulse counter alarms.
The LCD display and the 6 keys on the front panel allow a comfortable navigation through the menus, displaying data evaluation and managing the status of the inputs and outputs.
RAD.1 is equipped with a 4G GSM modem interface, such as: LTE Cat 1 bis + fallback to 2G or LTE Cat M1 + NB-IoT,
which allows the device to adapt to the most commonly used communication standards for worldwide connection.
RAD.1 is ATEX certified, making it the ideal solution for remote monitoring of fuel tanks, storage facilities, or any other materials at risk of fire or explosion.

Download

RAD.1 – data sheet

Dimensions
